Efficiency Adjustable Single Head Solar Panel Cleaning Brush Carbon Fiber Telescopic Pole
Three practical models of our Cleaning Brush are available to meet a variety of needs:
1.Plug-in Model
2.Lithium Battery-Powered Model
3.Dual-Purpose Model (incorporating the functions of the two models mentioned above)
To enhance usability, telescopic rods made from either carbon fiber or aluminum alloy are supplied to our clients. These rods are designed with superior performance as the top priority, featuring remarkable strength and long-term durability.
Taking into account the different configurations of solar panels, our telescopic rods are offered in three length choices: 3.6 meters, 5.4 meters, and 7.5 meters. This ensures they fit perfectly with various installation arrangements.
Our carbon fiber and aluminum alloy telescopic rods have a wide range of uses, and one of their outstanding applications is cleaning solar panels. We also provide customization services to modify specifications based on your specific needs, ensuring that your projects achieve optimal performance.
Key Features
1.Weight: The lightweight construction reduces user fatigue, making it suitable for extended periods of use.
2.Material: High-quality carbon fiber is used to manufacture the handle, which not only provides excellent rigidity but also keeps the weight extremely low.
3.Efficiency: Tough stains can be quickly removed by the rotating brush head. In addition, the anti-static design of the brush bristles lowers the risk of secondary dust pollution.
4.Length & Extension: The length can be fully adjusted, and the smooth telescopic operation allows for flexible reach and convenient compact storage.
5.Durability: The carbon fiber structure has anti-static properties and strong resistance to corrosion, UV radiation, and harsh environmental conditions.
6.Design: The brush head can be replaced quickly due to its modular design.
5 Excellent Advantages
1.Overall Lightweight Design:
The single-disc structure results in the product's small size and light weight. This overall lightweight design makes operation more effortless, labor-saving, and flexible, allowing it to handle complex photovoltaic array layouts easily. It is an excellent choice for those who pursue extreme lightness and flexible operation.
2.IP65-Grade Brushless Motor:
Brushless motors with IP65 protection level are carefully chosen. The product uses a fully encapsulated solution with thermally conductive epoxy resin, which balances heat dissipation and waterproof performance, ensuring it is not affected by harsh working environments. Compared with brushed motors, it runs more stably and has a service life 3-5 times longer, significantly reducing maintenance costs.
3.Dual Anti-Static Protection:
Anti-static nylon bristles are combined with anti-static carbon fiber telescopic rods to form a dual static elimination system. This system can effectively prevent the accumulation of static electricity, reduce the risk of electrostatic discharge, and ensure the safety of workers. It is especially suitable for dry and dusty environments.
(Note: Two rod materials are available—carbon fiber and aluminum alloy. This anti-static feature is only applicable to the carbon fiber version.)
4.Worry-Free Long Battery Life:
A large-capacity lithium battery is equipped in the lithium battery-powered model, which can provide a battery life of up to 6 hours after a full charge. This makes it an excellent option for long-term continuous operation in areas without power supply. It can also be connected to the mains power for non-stop work, completely solving the problem of power anxiety.
5.Dual-Mode Efficient Cleaning:
Floating dust and sand particles can be efficiently removed by the dry cleaning mode. As for the wet cleaning mode, it can be matched with multiple water supply solutions, enabling it to adapt effectively to complex environments such as mountains and deserts, and meet the high cleaning requirements of various scenarios.
| Product Name | Single Disc Solar Cleaning Brush RHINO700-EH1 | ||||
| Parameter Item | Product Model | ||||
| Plug-in Version | Lithium Battery Version | Dual-use Version | |||
| Power Supply | AC95V~264V;DC24V | Lithium Battery | AC95V~264V;DC24V or Lithium Battery | ||
| Motor Type | Brushless Motor | ||||
| Motor Speed | 360RPM | ||||
| Motor Voltage | DC 24V | ||||
| Telescopic Rod Material | Carbon Fiber | Aluminum Alloy | |||
| Telescopic Rod Wall Thickness | 1.2mm | 1mm | |||
| Number of Section | 3.6m | 2 | 3.6m | 3 | |
| 5.4m | 3 | 5.4m | 4 | ||
| 7.5m | 4 | 7.5m | 5 | ||
| Water Pipe Length | 20m (can be customized) | ||||
| Brush Hair Material | Anti-Static Nylon Yarn | ||||
| Cleaning Width | 340mm | ||||
| Lithium Battery Voltage | 24V | ||||
| Lithium Battery Capacity | 30AH | ||||
| Lithium Battery Charging Time | 4~6H | ||||
| Lithium Battery Life Per Full Charge | 5~6H | ||||
